Vertical Powder Spices Sachet Pouch Packaging Machine
Parameters:
(We have several models. We can customize the suitable one for you according to your requiredment.Just Tell us : Weight or Bag.)
| Modal | 320 | 420 | 520 | 720 |
| Measuring range | 150-800ml | 150-1500ml | 150-2000ml | 150-4000ml |
| Packaging speed | 5-70bags/min | 5-60bags/min | 10-60bags/min | 10-60bags/min |
| Bag width | 50-150mm | 60-200ml | 80-250mm | 100-350mm |
| Bag length | 80-240mm | 80-300mm | 80-350mm | 100-450mm |
| Film roll width | Max.320mm | Max.420mm | Max.520mm | Max.720mm |
| Film thickness | 0.03-0.09mm | |||
| Film material | OPP/CPP PET/PE PET-AL/PE lamination film,aluminum film | |||
| Machine weight | 350kg | 450kg | 550kg | 700kg |
Features:
1.Low cost high gain, high speed and efficiency.
2.The whole system is linkage control, automatic feeding, stop working without materials.
3.The contact parts with food is made of 316# high quality stainless steel, it will never get rust.
4. minimize the loss with complete automatic warn protection function;
5. the way of bag making: the machine can make pillow-type bag and standing bag according to customer's requirements.
Descriptions:
Application:
It is suitable for packing powder product, such as milk powder, wheat flour, coffee powder, tea powder, bean powder,spice powder, washing powder,seasoning powder,baking powder, bleaching powder. It integrates metering, bagging, packing, sealing, date printing and counting into one.chicken powder,etc
Package material: BOPP/CPP/VMCPP,BOPP/PE,PET/VMPET,PE,PET/PE,etc.
Various bag types are available, e.g. pouch, back-sealing bag,linking bags,etc.
Bag samples:
Pre-sale Service
1. Equipment model selection;
2.according to the special requirements of customers, personalized customized products;
3. Train technicians for customers free of charge;
4. Free professional technical engineers to plan the site on site and design the best process and plan.
5. Acceptance of the product;
6. Assist the client in drafting the construction plan;
Medium-sales Services
ECHO have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
After-sales Service
1.One Year Warranty,As long as there is a non-human fault in a year,free re-placement parts.
2.Parts Replacement,Don’t worry about the parts damaged or not sold after the machine is sold.we have a field factory with hundreds of enployees to serve you.
3.Engineer Asssignment,Lifelong maintentance,If your equipment breaks down,we will arrange engineers to repair it.
4.Online Instruction,We open online services,as long as your equipment failure,our engineers will be the first time for a one-to-one trou-bleshooting.
5.Feedback Survey,The engineer is required to bring a questionnaire to fill in the satisfaction with the engineer and the use of the equipment.
